    Water Cooled, Reciprocating, Lubricated, Non-Lubricated Compressors

    Enquiry
    Model Motor hp Comp. Piston Displacement Maximum Pressure Air Receiver (itrs.) Length Dimension (Inch)
        RPM CFM FAD PSIG kg/cm2     Width Height Lub Height NL Weight kgs.
    AC 7X5V 30 750 164 110 125 8.80 300 20 22 56 68 620
    AC 8X5V 40 750 215 143 100 7.00 300/500 20 22 56 68 680
    AC 8X7V 50 650 260 180 135 9.50 500/1000 20 28 66 70 818
    AC 9X7V 60 650 330 240 110 7.70 500/1000 22 28 66 79 840
    AC 11X7V 75 650 498 319 100 7.00 500/1000 25 28 75 88 1355
